Technical Specifications
| Model: AG Neovo QX-55 - 55" Surveillance Display | |
| Panel Spec | |
| Display Type | TFT-LCD |
| Size | 55" |
| Touch Screen | No |
| Resolution | 1920 x 1080 |
| Aspect Ratio | 16 : 9 |
| Color Depth | 8 bit |
| Contrast Ratio | 4000 : 1 |
| Backlight | LED |
| Viewing Angle | 178° (H), 178° (V) |
| Interfaces | |
| HDMI | 2 x HDMI 1.4 |
| VGA | 1 x VGA |
| Audio | 1 x Audio In, 1 x Audio Out |
| Power Inputs | |
| Power Consumption | 100W |
| Environmental | |
| Operating Temperature | 0 - 40°C |
| Storage Temperature | -20 - 60°C |
| Humidity | 10 - 90% RH, Non-Condensing |
| Physical Properties | |
| Housing | Metal |
| Weight | 27.5 kg (60.6 lb) |
| Dimensions (L x W x H) | 124.6 x 72.2 x 6.1 cm (49.1 x 28.4 x 2.4 in) |
| VESA Mount | 400 x 400 mm |
Resources
Description
Introducing the AG Neovo QX-55 - a top-of-the-line surveillance display designed to meet all your monitoring needs. With its impressive 54.6 inch UHD 3840x2160 resolution, this display delivers stunning visuals that bring every detail to life. The 450 nits of brightness ensure clear and vibrant images, even in well-lit environments.
Equipped with versatile connectivity options including VGA, DVI, HDMI, and DisplayPort inputs, the AG Neovo QX-55 allows for seamless integration with your existing surveillance system. Its anti-burn-in technology prevents image ghosting, ensuring that your display remains crisp and clear for extended periods of use. The NeoV Optical Glass screen adds an extra layer of protection, safeguarding the display from scratches and other damages.
- 55 inch screen size
- 4K UHD 3840 x 2160 resolution
- 450 nits of brightness
- Versatile connectivity: VGA, DVI, HDMI, DisplayPort inputs
- Anti-Burn-in technology prevents image ghosting
- NeoV Optical Glass screen protects the display from scratches and other damages
- RS232/ RJ45 connection for easy control and management
- Anti-glare surface treatment
In the Box
Frequently Asked Questions
Q: What is the AG Neovo QX-55 - 55" Surveillance Display?A: The AG Neovo QX-55 is a high-quality surveillance display designed specifically for security monitoring applications. It features a 55-inch display with Full HD resolution, advanced image processing technology, and a durable construction.
Q: What are the benefits of using the AG Neovo QX-55 for surveillance?A: The AG Neovo QX-55 offers several benefits for surveillance purposes, including: * Clear and detailed visuals: The Full HD resolution ensures that you can view surveillance footage with exceptional clarity and detail, allowing for accurate monitoring and identification. * Wide viewing angle: The display has a wide viewing angle, ensuring that you can see the footage clearly from various positions within the surveillance room. * Advanced image processing: The display utilizes advanced image processing technology to enhance the quality of the surveillance footage, making it easier to detect and analyze critical details. * Durable and reliable: The AG Neovo QX-55 is built to withstand the demands of continuous surveillance operations, ensuring long-term reliability and durability.
Q: What are the key features of the AG Neovo QX-55?A: The AG Neovo QX-55 offers a range of features that make it an ideal choice for surveillance applications, including: * 55-inch Full HD display with a resolution of 1920 x 1080 pixels. * Wide viewing angle of 178 degrees, ensuring clear visibility from different positions. * Image enhancement technologies, such as 3D comb filter and deinterlace, for improved image quality. * Multiple video inputs, including HDMI, VGA, and BNC, allowing for easy integration with surveillance systems. * Anti-Burn-In™ technology to prevent image retention and ensure long-term performance.
Q: In what scenarios can the AG Neovo QX-55 be beneficial?A: The AG Neovo QX-55 can be beneficial in various surveillance scenarios, including: * Security control rooms: The large display and high-resolution visuals enable security personnel to monitor multiple camera feeds simultaneously and identify potential threats effectively. * Retail environments: The display can be used to monitor store entrances, aisles, and cash registers, helping to prevent theft and ensure customer safety. * Transportation hubs: The AG Neovo QX-55 can be installed in airports, train stations, and bus terminals to monitor passenger flow and enhance security measures. * Industrial facilities: The display is suitable for monitoring critical areas in industrial settings, such as production lines, warehouses, and access points.
Q: How user-friendly is the AG Neovo QX-55?A: The AG Neovo QX-55 is designed with user-friendliness in mind. It features an intuitive interface and easy-to-use controls, allowing for effortless navigation and adjustment of settings. Additionally, the display is compatible with various surveillance systems, making it simple to integrate into existing setups.
